Claude Desktop MCP Config: File Location, JSON Example and Setup

You edited the JSON, restarted the app, and nothing happened. No hammer icon, no new tools, no error message. That silent failure is the most common story with a Claude Desktop MCP config, and it almost always traces back to one of three causes: you edited the wrong file, the JSON has a tiny syntax slip, or the app was never fully restarted. This article walks through all three, in the order you will meet them.

You will get the exact claude_desktop_config.json location on Windows and macOS (including the Windows MSIX trap that sends your edits into a file nobody reads), a working JSON example you can paste today, a way to confirm that a server really connected, and a short troubleshooting routine built around the MCP logs. Near the end there is a tutorial on using Claude Sonnet 5 on PicassoIA to debug your own config, plus a look at connecting image and video generators once the plumbing works.

💡 Short version: the file is claude_desktop_config.json, it needs a top-level mcpServers object, every path inside must be absolute, and the app must be fully quit and reopened after each edit.

Where the Config File Lives

Claude Desktop reads one JSON file at launch to find out which MCP servers (Model Context Protocol servers) it should start. The file does not exist until you open it from the settings screen or create it by hand, so a fresh install has nothing to find yet. Its location depends on your operating system and, on Windows, on how you installed the app.

Windows Path and the MSIX Trap

On a standard Windows install the file lives here:

%APPDATA%\Claude\claude_desktop_config.json

Copy Prompt

Expanded, that is C:\Users\<your name>\AppData\Roaming\Claude\claude_desktop_config.json. Press Win+R, paste the first form, and press Enter to open the right folder.

Here is the trap. When Claude Desktop is installed as an MSIX package (the Microsoft Store and some WinGet installs work this way), Windows virtualizes the AppData folder for that app. Several public bug reports describe the same result: the Edit Config button opens the plain %APPDATA% file, while the app itself reads a copy buried under the package folder:

%LOCALAPPDATA%\Packages\Claude_pzs8sxrjxfjjc\LocalCache\Roaming\Claude\claude_desktop_config.json

Copy Prompt

Edit the first file and your servers are ignored without a single warning. A quick PowerShell check tells you which situation you are in:

Test-Path "$env:LOCALAPPDATA\Packages\Claude_pzs8sxrjxfjjc"

Copy Prompt

If that prints True, put your mcpServers block in the packaged path, restart, and see whether the server appears. Package folder names can change between releases, so treat the path above as a starting point. If it does not match, look inside %LOCALAPPDATA%\Packages for a folder that starts with Claude_.

macOS Path and Linux Notes

On a Mac the file sits inside the Library folder, which Finder hides by default:

~/Library/Application Support/Claude/claude_desktop_config.json

Copy Prompt

In Finder, choose Go, then Go to Folder, and paste ~/Library/Application Support/Claude. From Terminal, open ~/Library/Application\ Support/Claude does the same job.

There is no official Linux build of Claude Desktop. Community builds usually follow the XDG convention and read ~/.config/Claude/claude_desktop_config.json, but check the notes of the build you use before you trust that path.

Open It From Settings

The least error-prone route is the app itself:

1. Click the Claude menu in your system menu bar (not the settings inside the chat window).
2. Choose Settings.
3. Open the Developer tab in the left sidebar.
4. Click Edit Config.

That creates the file when it is missing and shows it in your file manager. On a Windows MSIX install, compare the folder it opens with the packaged path above before you trust it.

Here is every location in one place:

What the JSON Looks Like

How the mcpServers Object Works

The whole file is one JSON object. Claude Desktop looks for a top-level property called mcpServers. Inside it, every property is one server, and the property name is the label you see in the app. Each entry is a small recipe for starting a program on your computer, and Claude talks to that program over standard input and output.

The right command depends on how the server was written. Node.js servers published to npm start with npx. Servers you built or cloned yourself start with node followed by the path to the compiled file. Python servers are usually launched through uvx, which needs the uv tool installed. In every case the rule is the same: whatever you type as command must work when typed into a terminal, because that is exactly what Claude Desktop does on your behalf.

If Claude Desktop already added other top-level entries to the file (newer builds can store a few preferences there), leave them alone and add mcpServers beside them. Replacing the whole file with a pasted snippet is how people lose those settings.

Examples for macOS and Windows

Here is the official filesystem server on a Mac. Swap username for your real account name:

{
  "mcpServers": {
    "filesystem": {
      "command": "npx",
      "args": [
        "-y",
        "@modelcontextprotocol/server-filesystem",
        "/Users/username/Desktop",
        "/Users/username/Downloads"
      ]
    }
  }
}

Copy Prompt

The Windows version is identical except for the paths, and every backslash must be doubled because a single backslash is an escape character in JSON:

{
  "mcpServers": {
    "filesystem": {
      "command": "npx",
      "args": [
        "-y",
        "@modelcontextprotocol/server-filesystem",
        "C:\\Users\\username\\Desktop",
        "C:\\Users\\username\\Downloads"
      ]
    }
  }
}

Copy Prompt

Three details do most of the work here. The -y flag lets npx install the server package without asking a question nobody is there to answer. The folders after the package name are the only places the server may touch. And all of those paths are absolute, because relative ones are a classic reason a server never starts.

You also need Node.js, since npx ships with it. Run node --version in a terminal; if it prints a version number, you are set, and the LTS release is the safe choice.

💡 Tip: pick the label in mcpServers for humans, not for the machine. filesystem, notes or weather are all fine, and the name only shows up in menus and in the log file name.

Add Servers and Secrets Safely

Environment Variables for Secrets

Real servers often need a credential. Put it in the env object of that server, never in args, where it would show up in process lists. This example runs two servers side by side:

{
  "mcpServers": {
    "filesystem": {
      "command": "npx",
      "args": [
        "-y",
        "@modelcontextprotocol/server-filesystem",
        "/Users/username/Documents/notes"
      ]
    },
    "weather": {
      "command": "node",
      "args": ["/Users/username/tools/weather-server/build/index.js"],
      "env": {
        "WEATHER_API_TOKEN": "paste-your-token-here"
      }
    }
  }
}

Copy Prompt

Notice the comma between the two server blocks and the absence of a comma after the last one. Those two spots cause more broken files than anything else.

The config file is plain text, so treat it like a password file. Do not commit it to a public repository, do not paste it into a chat or a screenshot with the token visible, and keep folder access narrow. A server runs with your user account permissions, which means it can do anything you can do by hand. Point the filesystem server at one project folder, not at your whole home directory.

Remote Servers Use Connectors Instead

The JSON file launches local processes. A hosted, remote MCP server is a different animal: it already runs somewhere else and you reach it by URL. Claude Desktop expects those to be added from Settings, then Connectors, not as entries in claude_desktop_config.json. Pasting a URL into command is one of the quieter ways to end up with a server that never loads.

Restart and Confirm It Works

Quit Fully, Then Reopen

Claude Desktop reads the config once, at launch. Saving the file does nothing on its own. Closing the window is not enough either, since the app can keep running in the background. On macOS press Cmd+Q or use Claude, then Quit. On Windows, quit from the system tray icon if the app lingers there. Then open it again.

Work in small steps. Add one server, restart, confirm it, then add the next. When you paste five servers at once and the file refuses to load, you have no way to tell which block broke it.

Check the Connectors Menu

Once the app is back, look at the chat input box and click the Add files, connectors, and more button. Hover over Connectors, click Manage connectors, and pick your server from the list. A working server shows the tools it offers. The filesystem server, for example, lists tools for reading files, writing files, moving them and searching them.

Then run a real test with a prompt such as "List the files in my Downloads folder." Claude asks for permission before it calls a tool. Approve the call, and the answer should come back with actual file names. If it replies that it has no access to your files, the server did not connect.

Fix Errors That Block Loading

Broken JSON Syntax

One misplaced character stops the whole file from loading. These are the usual suspects:

• A trailing comma after the last property or array item.
• A comment. JSON has none, so // lines are errors.
• Smart quotes pasted from a web page or word processor instead of plain straight quotes.
• A single backslash in a Windows path.
• A missing brace or bracket after you deleted a server block.

This snippet packs three of them into a few lines. Can you spot them?

{
  "mcpServers": {
    "filesystem": {
      "command": "npx",
      "args": ["-y", "@modelcontextprotocol/server-filesystem", "C:\Users\username\Desktop",],
    }
  }
}

Copy Prompt

The path uses single backslashes, the array ends with a comma before the closing bracket, and the args line ends with a comma before the closing brace. Fix all three and the file parses.

Before restarting, validate the file. Any JSON linter works, or you can use Node.js, which you already have:

node -e "JSON.parse(require('fs').readFileSync(process.argv[1],'utf8')); console.log('valid')" claude_desktop_config.json

Copy Prompt

If it prints valid, the syntax is fine and the problem is somewhere else.

Command Not Found Problems

When the JSON is valid but the server still fails, the culprit is usually the command. A desktop app does not read your shell profile, so a Node.js installed through a version manager can be invisible to it. Run which npx in a terminal and put the full path in the command field instead of npx.

First, run the exact command by hand to see whether it works outside the app:

npx -y @modelcontextprotocol/server-filesystem /Users/username/Desktop

Copy Prompt

On Windows, if the log mentions an error about ${APPDATA} inside a path, add the expanded value of %APPDATA% to that server's env block, for example "APPDATA": "C:\\Users\\username\\AppData\\Roaming\\". Also check that %APPDATA%\npm exists. If it does not, install npm globally with npm install -g npm, then restart the app.

Read the MCP Logs

The logs tell you what the app saw. Open the log folder from the table above and look for two kinds of files. mcp.log holds general messages about connections and failures. Files named mcp-server-NAME.log hold the stderr output of each server, which is often where the real error message lives. On a Mac you can follow them live:

tail -n 20 -f ~/Library/Logs/Claude/mcp*.log

Copy Prompt

On Windows, PowerShell does the same job:

Get-Content "$env:APPDATA\Claude\logs\mcp.log" -Tail 40 -Wait

Copy Prompt

A log that never changes after a restart is itself a clue: the app is probably reading a different config file than the one you edited, which brings you back to the MSIX path.
