How to Build an MCP Server Locally and Connect It to Claude (With Working Code)

Most MCP tutorials stop at "hello world" and leave you staring at a red Disconnected badge. This one ends with a server running on your own machine, Claude calling its tools, and a short checklist for the failures that bite most people. You will write about 70 lines of TypeScript, test them in a browser-based inspector, and wire the result into both Claude Desktop and Claude Code.

The server is a small notes tool: Claude can save a note to a JSON file on your disk and search it later. It is deliberately plain, because the plumbing is identical whether your tools read a notes file, query a database, or call an image model. I compiled and ran the server file below against version 1.32 of the TypeScript SDK, so the code builds exactly as shown.

What You Are Actually Building

MCP in Two Paragraphs

The Model Context Protocol (MCP) is an open standard, introduced by Anthropic in November 2024, that lets an AI app talk to outside tools in one consistent way. Instead of every app inventing its own plugin format, an MCP server exposes capabilities, and an MCP client such as Claude Desktop or Claude Code finds and calls them. Messages are plain JSON-RPC 2.0, so a server can be written in any language.

A server can offer three kinds of things:

• Tools: functions the model can call, like "save a note" or "run a query".
• Resources: read-only data the app can load as context, like a file or a database record.
• Prompts: reusable prompt templates that the user triggers on purpose.

This tutorial sticks to tools, because they are the simplest to test and the most useful on day one.

Why Run It Locally

A local server runs as a child process of the client, on your machine, with your files and your permissions. Nothing is exposed to the internet, there is no hosting bill, and iteration is fast: edit a file, rebuild, restart. The transport it uses is stdio: the client launches your program and talks to it through standard input and output.

💡 Good to know: Streamable HTTP replaced the older HTTP+SSE transport in the 2025-03-26 spec revision. And because a browser cannot launch a process on your computer, a stdio server cannot be added to claude.ai in the browser. Only remote servers work there.

Set Up the Project

What You Need Installed

Claude Desktop ships for macOS and Windows. On Linux, use the Claude Code route in the connection section below; the server itself is identical.

Create and Configure the Project

mkdir local-notes-mcp && cd local-notes-mcp
npm init -y
npm install @modelcontextprotocol/sdk zod
npm install -D typescript @types/node
mkdir src

Copy Prompt

Open package.json and add three things next to the dependencies npm created: the ES module flag and two scripts.

{
  "name": "local-notes-mcp",
  "version": "1.0.0",
  "type": "module",
  "scripts": {
    "build": "tsc",
    "start": "node build/index.js"
  }
}

Copy Prompt

Then create tsconfig.json in the project root:

{
  "compilerOptions": {
    "target": "ES2022",
    "module": "Node16",
    "moduleResolution": "Node16",
    "outDir": "build",
    "rootDir": "src",
    "strict": true,
    "esModuleInterop": true,
    "skipLibCheck": true,
    "types": ["node"]
  },
  "include": ["src"]
}

Copy Prompt

⚠️ Watch out: TypeScript 7, the version npm installs today, no longer loads @types packages on its own. Without the "types": ["node"] line you get Cannot find name 'process' and similar errors on every Node import.

Write Your First Two Tools

The Full Server File

Save this as src/index.ts. It exposes save_note and search_notes, and stores everything in one JSON file.

import { McpServer } from "@modelcontextprotocol/sdk/server/mcp.js";
import { StdioServerTransport } from "@modelcontextprotocol/sdk/server/stdio.js";
import { z } from "zod";
import { promises as fs } from "node:fs";
import os from "node:os";
import path from "node:path";

const NOTES_DIR = process.env.NOTES_DIR ?? path.join(os.homedir(), "mcp-notes");
const NOTES_FILE = path.join(NOTES_DIR, "notes.json");

type Note = { id: number; title: string; body: string; createdAt: string };

async function readNotes(): Promise<Note[]> {
  try {
    return JSON.parse(await fs.readFile(NOTES_FILE, "utf8"));
  } catch {
    return [];
  }
}

const server = new McpServer({ name: "local-notes", version: "1.0.0" });

server.registerTool(
  "save_note",
  {
    title: "Save note",
    description: "Save a short note with a title and a body to the local notes file.",
    inputSchema: {
      title: z.string().min(1).max(120).describe("Short title for the note"),
      body: z.string().min(1).describe("The text of the note"),
    },
  },
  async ({ title, body }) => {
    const notes = await readNotes();
    const note: Note = {
      id: notes.length + 1,
      title,
      body,
      createdAt: new Date().toISOString(),
    };
    await fs.mkdir(NOTES_DIR, { recursive: true });
    await fs.writeFile(NOTES_FILE, JSON.stringify([...notes, note], null, 2));
    return { content: [{ type: "text", text: `Saved note #${note.id}: ${title}` }] };
  }
);

server.registerTool(
  "search_notes",
  {
    title: "Search notes",
    description: "Find saved notes whose title or body contains a word or phrase.",
    inputSchema: {
      query: z.string().min(1).describe("Word or phrase to look for"),
    },
  },
  async ({ query }) => {
    const q = query.toLowerCase();
    const hits = (await readNotes()).filter((n) =>
      `${n.title} ${n.body}`.toLowerCase().includes(q)
    );
    if (hits.length === 0) {
      return { content: [{ type: "text", text: `No notes match "${query}".` }] };
    }
    const text = hits.map((n) => `#${n.id} ${n.title}\n${n.body}`).join("\n\n");
    return { content: [{ type: "text", text }] };
  }
);

const transport = new StdioServerTransport();
await server.connect(transport);
console.error("local-notes MCP server running on stdio");

Copy Prompt

What Each Part Does

• McpServer is the high-level class. The name and version you pass show up in the client's server list and logs.
• registerTool takes a tool name, a config object (title, description, inputSchema), and an async handler.
• The Zod schema is validated before your handler runs, then converted to JSON Schema so Claude can read it. Every .describe() string reaches the model.
• The return value is always { content: [...] }. Plain text is the simplest content type; images and resource links are also supported.
• StdioServerTransport reads requests from stdin and writes responses to stdout.

💡 Tip: Write descriptions for the model, not for humans. "Find saved notes whose title or body contains a word or phrase" tells Claude when to call the tool. "Search" does not. Claude picks tools mostly from their names and descriptions.

Because search_notes never changes anything, mark it that way in its config: annotations: { readOnlyHint: true }. Hints are advisory, and clients decide for themselves how much to trust them, but they let well-behaved clients treat read-only tools more gently.

Never Print to Stdout

With stdio, stdout is the protocol channel. One stray console.log("started") pushes a non-JSON line into the stream, and most clients will drop the connection or show the server as failed. Remember this rule and you will skip the most common first-day failure:

• Do: console.error("message"), which writes to stderr, where clients collect logs.
• Don't: console.log(...) or process.stdout.write(...) anywhere in your server, including inside libraries you import.

Test It Before Claude Does

Run the MCP Inspector

The MCP Inspector is the official debugging tool. It launches your server the same way a client would and gives you buttons instead of prompts.

npm run build
npx @modelcontextprotocol/inspector node build/index.js

Copy Prompt

A page opens in your browser. Click Connect, open the Tools tab, and press List Tools. You should see save_note and search_notes with their schemas. Run save_note with a title and a body, then run search_notes with a word from that body. The first call returns Saved note #1: Standup, and the notes file appears in a mcp-notes folder inside your home directory (or in NOTES_DIR if you set it).

Send Raw JSON-RPC Messages

If you want to see the protocol itself, stdio uses one JSON message per line. Put these three lines in requests.jsonl:

{"jsonrpc":"2.0","id":1,"method":"initialize","params":{"protocolVersion":"2025-06-18","capabilities":{},"clientInfo":{"name":"smoke","version":"0.0.1"}}}
{"jsonrpc":"2.0","method":"notifications/initialized"}
{"jsonrpc":"2.0","id":2,"method":"tools/list"}

Copy Prompt

Then feed them to the server and keep stdin open for a moment so the replies can flush:

(cat requests.jsonl; sleep 2) | node build/index.js

Copy Prompt

The first reply confirms the handshake, with the protocol version the server agreed on and your serverInfo:

{"result":{"protocolVersion":"2025-06-18","capabilities":{"tools":{"listChanged":true}},"serverInfo":{"name":"local-notes","version":"1.0.0"}},"jsonrpc":"2.0","id":1}

Copy Prompt

The second reply lists both tools with their JSON Schemas. That exchange is everything Claude does when it connects: handshake, list tools, call tools.

Connect It to Claude

Edit the Claude Desktop Config

In Claude Desktop, open Settings, then Developer, then Edit Config. That reveals claude_desktop_config.json:

Add your server under mcpServers. Use absolute paths, because Claude Desktop launches your process from its own working directory, not from your project folder.

{
  "mcpServers": {
    "local-notes": {
      "command": "node",
      "args": ["C:/Users/you/projects/local-notes-mcp/build/index.js"],
      "env": {
        "NOTES_DIR": "C:/Users/you/mcp-notes"
      }
    }
  }
}

Copy Prompt

On macOS the path looks like /Users/you/projects/local-notes-mcp/build/index.js. Save the file, then fully quit Claude Desktop (on Windows, from the system tray, not just the window's close button) and reopen it. Your tools appear in the chat input's tools menu, and Claude asks for permission before running one.

Add It to Claude Code

Claude Code needs no file editing. One command registers the server:

claude mcp add --transport stdio --env NOTES_DIR=/home/you/mcp-notes local-notes -- node /home/you/projects/local-notes-mcp/build/index.js

Copy Prompt

Everything after the double dash is the command that launches your server. Check it with claude mcp list, or type /mcp inside a session to see its status. A scope flag decides who gets the server:

Try a Real Prompt

Ask Claude something that forces a tool call:

Save a note titled "Standup" that says "Ship the MCP post on Friday". Then search my notes for "Friday".

Claude calls save_note, then search_notes, and quotes the result back. Open notes.json to confirm the data landed on your disk. If it did, you have a working local MCP server.

Fix Failures and Lock It Down

Fix the Common Failures

Two Windows details cause half of the remaining trouble. Backslashes inside JSON strings must be doubled (C:\\Users\\you\\...), or you can simply use forward slashes as in the example above. And on native Windows, servers launched through npx usually need a cmd /c wrapper in command; a plain node command does not.

When something still fails, read the logs. Claude Desktop writes one log per server, in ~/Library/Logs/Claude on macOS and in %APPDATA%\Claude\logs on Windows. Your own console.error lines end up there.

Safe Defaults Worth Keeping

A stdio server inherits your permissions, so treat every tool as code that can act as you.

• Limit the blast radius. Keep file access inside one folder. If a tool accepts a path, resolve it and reject anything outside the allowed directory.
• Validate every input. Zod's min, max and enum rules cost nothing and block malformed calls before your handler runs.
• Keep secrets out of code. Put tokens in the env block of your config, and keep that file out of version control.
• Read before you install. Only add third-party servers whose source you have looked at. They run with your account's access.
• Treat tool output as untrusted. Text your tool fetches from web pages or emails can contain instructions aimed at the model. Return it as data and keep write actions behind confirmation.

Moving From stdio to HTTP

When teammates need the same tools, swap the transport. The SDK ships StreamableHTTPServerTransport, which serves the same McpServer over HTTP behind your own authentication. Your registerTool calls do not change. Only the transport and the client registration do, for example claude mcp add --transport http notes https://your-host/mcp.
