A working MCP elicitation example for client support: a TypeScript server that pauses a ticket escalation, asks the agent for priority, product area and outage status through a form, then resumes. Includes the Claude Code setup, decline and cancel handling, and a test checklist.
Your support agent types "escalate SUP-1042" into Claude Code and the tool starts running. Then it stalls, because nobody told it the priority, the product area, or whether customers are locked out. A weak setup guesses and pages the wrong team. A better one asks. That question, sent from the server back to the person at the terminal, is what MCP elicitation does. This MCP elicitation example for a client support desk shows the whole loop: the server code, the form schema, the Claude Code setup, and what to do when the agent says no.
Everything below targets the 2025-11-25 revision of the Model Context Protocol and the TypeScript SDK. The server is small enough to read in one sitting, and every part of it maps to a rule in the spec.
Normally an MCP client calls a tool, the server works, and a result comes back. Elicitation adds one step in the middle. While a tool is running, the server sends an elicitation/create request to the client. The client shows the person a dialog, collects an answer, and returns it. The tool then continues with real data instead of a guess.
That makes elicitation a human in the loop primitive. The server stays in charge of what it needs. The client stays in charge of how the question looks, which servers may ask, and whether the person is allowed to refuse.
The spec defines two modes:
requestedSchema, and the client renders a form from it.Form schemas are deliberately small. They are flat objects with primitive properties only:
| Schema type | Useful options | Typical use |
|---|---|---|
| string | minLength, maxLength, pattern, format (email, uri, date, date-time) | Contact email, short note |
| number or integer | minimum, maximum, default | Customers affected |
| boolean | default | "Is this an outage?" |
| single-select enum | enum, or oneOf with titles | Priority, product area |
| multi-select enum | array with minItems and maxItems | Affected platforms |
Nested objects and arrays of objects are left out on purpose, so any client can draw the form without guessing.
Every response carries an action:
content holds the values.Your server has to treat all three as normal outcomes. Most elicitation bugs come from handling only the first one.
Picture a support team with a helpdesk full of tickets and a small on-call rota. Agents work inside Claude Code, and an MCP server called support-desk gives the model one write action: escalate_ticket. It takes a ticket ID and hands the case to the right engineers.
The model can read a ticket and infer a priority. It will often be right. When it is wrong, a billing question lands in the incident channel, or a login outage sits in a slow queue overnight. You could widen the tool's input schema and hope the model fills every field correctly, but a tool call with invented values looks identical to one with real values.
Elicitation moves the decision to the person who owns it. The model supplies the ticket ID. The human supplies the judgment.
Five fields are enough. More than that and agents start dismissing the dialog.
| Field | Type | Why it is there |
|---|---|---|
| priority | single-select enum | Routes to the right on-call queue |
| area | single-select enum | Picks the owning team |
| affectedCustomers | integer, 1 to 10000 | Separates one user from a wide incident |
| customerEmail | string, format email | Lets the engineer follow up |
| outage | boolean | Opens the incident channel |
Only priority and area are required. The others have defaults, so an agent in a hurry can accept and move on.
💡 Keep the form short. Each extra field is a reason for the agent to press cancel.
The server is one TypeScript file, a stdio transport, and two small dependencies.
mkdir support-desk-mcp && cd support-desk-mcp
npm init -y
npm pkg set type=module
npm install @modelcontextprotocol/sdk zod
npm install -D typescript tsx @types/node
mkdir src
Setting type to module lets the file use top-level await and ES imports.
Save this as src/server.ts:
import { McpServer } from "@modelcontextprotocol/sdk/server/mcp.js";
import { StdioServerTransport } from "@modelcontextprotocol/sdk/server/stdio.js";
import { z } from "zod";
const server = new McpServer({ name: "support-desk", version: "1.0.0" });
const EscalationForm = z.object({
priority: z.enum(["p1", "p2", "p3"]),
area: z.enum(["billing", "login", "api", "mobile-app"]),
affectedCustomers: z.number().int().min(1).max(10000).default(1),
customerEmail: z.string().email().optional(),
outage: z.boolean().default(false),
});
// Stub: swap in your helpdesk API call.
async function createEscalation(ticketId: string, data: z.infer<typeof EscalationForm>) {
return `ESC-${Date.now().toString(36).toUpperCase()}`;
}
const reply = (text: string, isError = false) => ({
content: [{ type: "text" as const, text }],
isError,
});
server.registerTool(
"escalate_ticket",
{
description: "Escalate a support ticket to the on-call team. Asks the agent for missing details.",
inputSchema: { ticketId: z.string().describe("Ticket ID, for example SUP-1042") },
},
async ({ ticketId }) => {
if (!server.server.getClientCapabilities()?.elicitation) {
return reply("This client cannot show forms. Ask the agent for priority and area, then retry.", true);
}
const answer = await server.server.elicitInput({
message: `Ticket ${ticketId} needs a few details before it reaches the on-call team.`,
requestedSchema: {
type: "object",
properties: {
priority: {
type: "string",
title: "Priority",
oneOf: [
{ const: "p1", title: "P1 Service down" },
{ const: "p2", title: "P2 Major feature broken" },
{ const: "p3", title: "P3 Minor issue" },
],
},
area: {
type: "string",
title: "Product area",
enum: ["billing", "login", "api", "mobile-app"],
},
affectedCustomers: {
type: "integer",
title: "Customers affected",
minimum: 1,
maximum: 10000,
default: 1,
},
customerEmail: { type: "string", format: "email", title: "Customer email" },
outage: { type: "boolean", title: "Is this an outage?", default: false },
},
required: ["priority", "area"],
},
});
if (answer.action === "decline") {
return reply(`The agent declined to escalate ${ticketId}. The ticket is unchanged.`);
}
if (answer.action === "cancel") {
return reply(`Escalation of ${ticketId} was cancelled. Nothing was changed.`);
}
const parsed = EscalationForm.safeParse(answer.content);
if (!parsed.success) {
return reply("The form answers were invalid. Ask again.", true);
}
const escalationId = await createEscalation(ticketId, parsed.data);
return reply(`Escalated ${ticketId} as ${parsed.data.priority} in ${parsed.data.area}. Reference ${escalationId}.`);
}
);
await server.connect(new StdioServerTransport());
Notice that mode is missing from the elicitInput call. Form mode is the default, which keeps the request readable by older clients.
The first lines of the handler matter more than they look. A client that supports elicitation declares an elicitation capability during initialization. An empty elicitation object counts as form mode only, and a server must never send a mode the client did not declare.
If the capability is missing, the server returns a plain-text error instead of hanging. The model reads that message and asks the agent in chat. A tool that fails politely beats a tool that freezes.
💡 In a stdio server, never print to standard output. Stray
console.loglines corrupt the protocol stream. Send debug output withconsole.error.
With the server written, Claude Code needs to know it exists.
From any folder, add it with the CLI. Everything after the double dash is the command that launches the server:
claude mcp add support-desk -- npx -y tsx /absolute/path/to/support-desk-mcp/src/server.ts
To share the setup with teammates, add --scope project. Claude Code then writes a .mcp.json file at the repository root:
{
"mcpServers": {
"support-desk": {
"type": "stdio",
"command": "npx",
"args": ["-y", "tsx", "/absolute/path/to/support-desk-mcp/src/server.ts"]
}
}
}
| Scope | Loads in | Shared with the team | Stored in |
|---|---|---|---|
| local (default) | Current project only | No | ~/.claude.json |
| project | Current project only | Yes, through version control | .mcp.json |
| user | All your projects | No | ~/.claude.json |
💡 On native Windows, wrap the launcher:
claude mcp add support-desk -- cmd /c npx -y tsx C:\path\to\src\server.ts.
Two checks tell you the server is alive:
claude --version
claude mcp list
Inside a session, /mcp opens the server panel with connection status. You should see support-desk listed as connected.
If a server stops connecting after an update, check the Claude Code changelog. The notes for 2.1.287, which added URL prompts from servers on the 2025-11-25 protocol, say to add "bareElicitationCapability": true to that server's config entry when it no longer connects.
Start a session in your project and type a plain request:
Escalate ticket SUP-1042 using the support-desk tool.
Claude calls mcp__support-desk__escalate_ticket. The tool pauses, Claude Code shows the form, and the agent fills in priority, area, customers affected, email and the outage flag.
After the agent submits, the tool resumes and returns something like Escalated SUP-1042 as p1 in login. Reference ESC-LQ3F9A2. The model can quote that reference straight into its reply.
Claude Code also exposes Elicitation and ElicitationResult hooks, matched on the server name. A script can answer a known form on its own, or log every response before it reaches the server. Use that for low-risk forms in automation, and keep people in front of anything that touches customers.
Happy-path demos hide the part that decides whether agents trust the tool. People close dialogs, change their minds and fat-finger values.
| Action | What the person did | What the tool should do |
|---|---|---|
| accept | Submitted the form | Validate again, then create the escalation |
| decline | Said no on purpose | Leave the ticket alone, report it, offer a manual route |
| cancel | Closed the dialog | Change nothing, allow a retry later |
Notice the safeParse call in the server. Clients should validate answers against the schema, and servers should do it again. Defaults and formats are hints for the interface, not guarantees about the data that arrives.
Return an isError result for bad input rather than throwing. The model sees the message and can ask the agent to run the tool again.
Most failures come from a short list of habits.
The spec is blunt: servers must not request passwords, API tokens or payment credentials through form mode. Form answers pass through the client, so they can end up in logs and transcripts. Anything secret belongs in URL mode, where the person types it into a page the client cannot read.
A name or an email address is different. The server may ask for those, and the person can review and decline.
A requestedSchema with a nested object or a list of objects will be rejected or rendered badly. Flatten it. If you need a list of line items, run several small elicitations or accept a multi-select enum.
Other habits that cause trouble:
Run these five cases before real tickets touch the tool:
affectedCustomers becomes 1.You can also run the server under the MCP Inspector from the project folder with npx @modelcontextprotocol/inspector npx tsx src/server.ts to watch the raw elicitation/create messages go by.
